Life Science
Surgical Tools
Limited Reuse Biopsy Punch
Overview
Our reusable biopsy punches are multi-purpose sampling tools designed with a retractable cutting cannula. They are easy to operate, efficient, safe, fast and precise. Our punches consists of a razor sharp stainless steel cutting tip. It is designed to cut, retrieve and store the cored samples from a source materials. The source could be skin, tissue, gels, paper, cloth, leaves, paint chips, films or other thin, soft substrates. The biopsy punches are recommended as a DNA sampling tool and are also ideal for forensic use and laboratory sampling applications. The punches come sterile and are individually wrapped. They were sterilized using ethylene oxide.
Features
- Individual sterile packs
- Limited reuse
- Tip material: 304 stainless steel
- Sterilization: Autoclaving for 20 minutes at 250°F.
- The maximum sample depth is 2mm
Options
| Order code | Size (mm) | ID (mm) | OD (mm) | Wall thickness (mm) |
| 504638 | 0.35 | 0.33 | 0.63 | 0.15 |
| 504528 | 0.5 | 0.5 | 0.8 | 0.15 |
| 504529 | 0.75 | 0.77 | 1.07 | 0.15 |
| 504646 | 1 | 0.96 | 1.26 | 0.15 |
| 504530 | 1.2 | 1.2 | 1.5 | 0.15 |
| 504647 | 1.5 | 1.5 | 1.9 | 0.2 |
| 504531 | 2 | 2 | 2.4 | 0.2 |
| 504648 | 2.5 | 2.5 | 2.9 | 0.2 |
| 504649 | 3 | 3 | 3.4 | 0.2 |
| 504650 | 3.5 | 3.5 | 3.9 | 0.2 |
| 504651 | 4 | 4 | 4.4 | 0.2 |
| 504532 | 5 | 5 | 5.5 | 0.25 |
| 504533 | 6 | 6 | 6.5 | 0.25 |
| 504534 | 7 | 7 | 7.5 | 0.25 |
| 504535 | 8 | 8 | 8.5 | 0.25 |
Our reusable biopsy punches are multi-purpose sampling tools designed with a retractable cutting cannula. They are easy to operate, efficient, safe, fast and precise. Our punches consists of a razor sharp stainless steel cutting tip. It is designed to cut, retrieve and store the cored samples from a source materials. The source could be skin, tissue, gels, paper, cloth, leaves, paint chips, films or other thin, soft substrates. The biopsy punches are recommended as a DNA sampling tool and are also ideal for forensic use and laboratory sampling applications. The punches come sterile and are individually wrapped. They were sterilized using ethylene oxide.
Our biopsy punches is a limited reusable, disposable sampling tools. They may be disposed of after use or cleaned and reused.
Cleaning
- Clean tip between each sample extraction by coring blank filter paper.
- Rinse with ethanol or spray with compressed air to remove dried artifacts.
- Rinse mat with ethanol after each sample extraction.
Specifications
| Material | PP - body 304 stainless steel - cutting cannula (tip) |
| Packing | individually wrapped |
| Sterilization | Autoclaving for 20 minutes at 250°F. |
| Patent | US patent pending no. 14/335,975 |
| Origin | Taiwan |
| Specifications | Kindly refer to the "Overview" tab. |
